Features
- Size: 6"
- Trim Finish: White, Semi-Specular with White Flange
- Wattage: 13.6-24.5W
- Voltage: 120/277V
- Color Temperature: 3000K, 3500K, 4000K
- Lumens: 1000/1500/2000lm Selectable
- CRI: 80+
- Dimming: 0-10V
- Beam Spread: General Ambient (90˚+)
- Non-IC
- Equipped with 9 knockouts: four 3/4" and two 1" trade size knockouts on top , three 3/4" trade size knockouts on sides. Approved for 8 (four in, four out) #12 AWG 70°C
Dimensions
- Housing Length: 14"-24"
- Housing Width: 12.5"
- Housing Height: 3.17"
- Trim Diameter: 7.24"
- Trim Height: 2.54"
Lamping
- Up to 24.5W LED
