Compatible Fixtures (Sold Separately):
Features
- Max Output Current: 5A
- Max Output Power: 120W
- Input Voltage: 5-24V DC
- Output Voltage: 5-24V DC
- Output Signal: SPI x 2
- Input Signal: Meshle app + Bluetooth mesh
- Min Supported Version: Bluetooth Low Energy 4.1
- WiFi Supported: 2.4 GHz
- Max Pixel Dots: 600
- Multi-pixel LED strip controller with SPI signal output
- Lighting Modes Available: DIM, CCT, RGB, RGBW, RGBTW
- One controller could operate up to 495-ft (150m) of Light by Lotus RGBTW strips
- Max distance from router to ensure stable operation: 50 ft (15 m) indoor / 100 ft (30 m) outdoor
- SPI controlled strips are directional
- Automatic power cutoff after 10 seconds when the LED is turned off
- Compatible with MESHLE: Enables wireless connection with other devices in a Bluetooth Mesh Network and control via the MESHLE app
- Offers group control capability: can be operated individually or as part of a group
- IP 20 rated
Dimensions
- Length: 4.49"
- Width: 1.5"
- Height: 0.79"
