Class 2 power supplys are intrinsically safer power supplys because they are
compartmentalized to allow no greater than 5 amps of current to be drawn on
each compartment. Enclosure cover is easy to remove. Power supply has
knockouts on three sides with clips for line voltage wiring. Secondary wiring
for class 2 power supplys do not require conduit sheathed cable or clamp
wiring techniques.
Features
- Finish: Black
- Wattage: 60W
- Input Voltage: 100-277 VAC
- ELV Dimming: 100-5%
- TRIAC Dimming: 100-5%
- High Power factor > 0.9, and THD < 20%
- Short circuit, over current, over voltage, over temperature protection
- Dimming with TRAIC/ELV dimmers
- Class 2 Output
- FCC Part 15 Class B Compliant
- Rated Life: 50000 Hours
Dimensions
- Length: 8.81"
- Width: 2.06"
- Height: 1.25"
