Features
- Finish: Black, White
- Power: 22W
- Input: 48 VDC
- Color Temperature: 2700K, 3000K, 3500K, 4000K
- Delivered Lumens: 990-1335
- CRI: 90
- ELV Dimming: 100-0.1%
- 0-10V Dimming: 100-0.1%
- TRIAC Dimming: 100-0.1%
- Beam: 15°-50°
- Automated beam adjustment
- Motorized head adjustment
- Rated Life: 50000 Hours
- Construction: Die-cast Aluminum, Clear Lens
- Wireless or DMX hardwire 360° panning, 0-90° tilting, dimming, and 15-50° beam angle adjustment
- To enable access to VENTRIX element releasing tabs, maintain at least 3” of free channel space
- Driver concealed within the fixture
- Can be mounted on ceiling or wall vertically or horizontally
Dimensions
- Length: 8"
- Width: 1.5"
- Height: 8.25"
