Features
- Finish: Black/Black, Black/Gold, Black/White, White/Black, White/Gold, White/White
- Power: 15W
- Input: 48 VDC
- Color Temperature: 2700K, 3000K, 3500K, 4000K
- Delivered Lumens: 370-760
- CRI: 90
- ELV Dimming: 100-0.1%
- 0-10V Dimming: 100-0.1%
- TRIAC Dimming: 100-0.1%
- Beam: 15°-45°
- Rated Life: 50000 Hours
- Construction: Extruded Aluminum with PC retractable accenting collar
- Easy wiring adjustment with cable-gripper on fixture body
- Retractable accenting collar available in multiple finishes extends up to 3/8" to create two-tone finish
- No splicing required for pendant height adjustment on VENTRIX
- To enable access to VENTRIX element releasing tabs, maintain at least 3” of free channel space
- Driver concealed within the fixture
Dimensions
- Width: 6"
- Height: 14"-120"
