Features
- Finish: Black, Chrome, Gold, Haze, White
- Power: 8.5W
- Input: 48 VDC
- Color Temperature: 2700K, 3000K, 3500K, 4000K
- Delivered Lumens: 420-650
- CRI: 90
- ELV Dimming: 100-0.1%
- 0-10V Dimming: 100-0.1%
- TRIAC Dimming: 100-0.1%
- Beam: 19°, 32°, 50°
- Low glare trim with 30° shielding angle
- Rated Life: 50000 Hours
- Construction: Die-cast Aluminum with injection molded low glare trim
- To enable access to VENTRIX element releasing tabs, maintain at least 3” of free channel space
- Driver concealed within the fixture
- May be installed side by side or at end of VENTRIX channel
- Can be mounted on ceiling or wall vertically or horizontally
Dimensions
- Length: 6"
- Width: 1.5"
- Height: 1.75"
