3-308 Pilar 2.8" LED Ceiling Mount

Oxygen LightingSKU: 3-308-115
filler

Shade Color: Opal Glass
Finish: Black
Voltage: 120V - 277V
Price:
$193
Stock:
In stock

Description

3-308 Pilar 2.8" LED Ceiling Mount

Features:

  • Finish: Black, Polished Nickel, Satin Nickel
  • Diffuser: White Opal Glass, Matte White Acrylic
  • Plated steel and acrylic construction
  • Delivered Lumen: Glass - 226 lm, Acrylic - 234 lm
  • Color Temperature: 3000K
  • CRI: 90
  • Voltage: 120V to 277V
  • Diffuser is 2.75” in diameter
  • Approved for ceiling and wall mounted applications
  • Cold rolled steel housing
  • Diffuser screws onto housing with integral threaded fitting
  • Driver mounts inside junction box
  • Glass difusser is 1/8" thick matte opal
  • Oxygen reserves the right to modify designs at any time
  • Total luminaire power 7.1w
  • Unit mounts a 4” octagonal junction box
  • Unit requires 2.5" deep junction box
  • TRIAC and ELV dimming at 120V AC; 0-10V dimming, 100% to 10% current output

Lamping:

  • 1 x 6.2W LED (Included)

Models:

3-308-115 , 3-308-120 , 3-308-124 , 3-308-215 , 3-308-220 , 3-308-224 , 37-308-115 , 37-308-120 , 37-308-124 , 37-308-215 , 37-308-220 , 37-308-224
