The IRIS 3" Round Shallow LED Downlight & Adjustable delivers precise architectural lighting in tight plenum spaces. Featuring field-interchangeable optics, 365° rotation, and 35° tilt, it provides accurate beam control and glare-free illumination. Designed for 2x4 shallow housings, this compact LED recessed downlight is ideal for residential and commercial applications.
Features
- Voltage: 120-277V
- Color Temperature: 2400K, 2700K, 3000K, 3500K, 4000K, 5000K
- Lumens: 250, 500, 900, 1300
- CRI: 90
- 0-10V 1% dimming
- Designed for 2x4 construction
- Interchangeable precision optics: 8°, 10°, 12°, 15–70° in 5° increments, and asymmetric patterns
- 365° of rotation and 35° of tilt for precise hot aiming
- Unmatched trims and finishes for every space and style
- Trim flange options: Millwork/Plaster Knife Edge Rimless, MicroFlange, or Standard Flange
- Servicable from Below: LED Light engine and magnetic snap-in driver
- Integral or remote driver options
Dimensions
- Length: 17.05"
- Width: 14.33"
- Height: 3.45"
Warranty
- 5-year warranty
Documents
Labels and Listings
- cULus Certified to UL 1598 / C22.2 No. 250 suitable for wet locations with lensed trims (required for outdoor use); damp location with open trims
- ENERGY STAR qualified
- Insulated ceiling (IC) rated
- Airtight per ASTM-E283
- FCC CFR Title 47 Part 15 Class B at 120VAC and Class A at 277VAC
- Declare compliant, LBC Red List approved
- RoHS compliant
- Can be used for State of California Title 24 high efficacy LED compliance under JA8, reference Modernized Appliance Efficiency Database System (MAEDBS) for 2019 JA8 High Efficacy Lighting
